DIN 7985 M 5 x 30 A2-H
DIN 7985 M 5 x 30 A2-H
DIN 7985 Cross recessed raised cheese head screws
Technical data
| Cross recess size: | 2 |
|---|---|
| Drive type: | Cross slot |
| Head diameter (dk): | 10 |
| Head form: | raised countersunk head |
| Head heigth (k): | 3,8 |
| Length (l): | 30 |
| Lens point heigth (c): | 1.3 |
| Material: | A2 |
| Quality: | - |
| Surface: | plain |
| Thread (d): | M 5 |
Graduated prices
| Quantity | Price |
|---|---|
| To 999 | €33.05 / 100 pcs |
| To 1999 | €30.85 / 100 pcs |
| To 2999 | €28.65 / 100 pcs |
| From 3000 | €26.44 / 100 pcs |
Further information
TBD
Description
Art.-No.
Availability
173788
available
€33.05
/ 100 pcs
Content:
1 pcs
(€33.05* / 100 pcs)
