DIN 70852 M 26 x 1,5 17H
DIN 70852 M 26 x 1,5 17H
DIN 70852 Groove nut quality 17H
Technical data
| Count of groove: | 4 |
|---|---|
| Drive type: | Groove |
| Groove depth (c): | 2.8 |
| Groove width (b): | 6.5 |
| Height (k): | 7 |
| Material: | Steel |
| Outside diameter (d2): | 40 |
| Quality: | 17H |
| Surface: | plain |
| Thread (d): | M 26 |
Graduated prices
| Quantity | Price |
|---|---|
| To 49 | €1,006.14 / 100 pcs |
| To 99 | €943.25 / 100 pcs |
| To 199 | €880.37 / 100 pcs |
| To 299 | €817.49 / 100 pcs |
| From 300 | €754.60 / 100 pcs |
Further information
TBD
Description
Art.-No.
Availability
035910
available
€1,006.14
/ 100 pcs
Content:
1 pcs
(€1,006.14* / 100 pcs)
